Τεχνολογία 3D Printing
|
Laser Metal Deposition (LMD)
|
|
Laser System
|
1.0/1.4 kW 9 x 450 nm direct diode lasers
|
|
Printhead
|
Mounted on the right side of the spindle 32.5 to 35 kg
|
|
Printhead Retracted Size (WxDxH)
|
280 x 332 x 684 mm
|
|
Printhead Unretracted Size (WxDxH)
|
280 x 332 x 943 mm
|
|
Control Unit
|
Wall mounted, air-cooled 80.5 kg 600 x 300 x 800 mm
|
|
Human Machine Interface
|
Wall mounted 17” tactile screen
|
|
Cooling
|
Water-cooled deposition head. Chiller Included
|
|
Λογισμικό
|
Meltio relies on its Software Partners Ecosystem for the Hybrid process, including additive and subtractive
|
|
Print Envelope (WxDxH)
|
Depending on the Machining Center
|
|
Feeder System
|
Quad-point traction servo feeders, frictionless liners
|
|
Process Control
|
Melt Pool Camera & Closed-loop wire modulation
|
|
Power Input
|
200/240 V 3W+PE 380/415 V 3W+N+PE
|
|
Κατανάλωση Ενέργειας
|
9.2 kW peak 1.0 / 1.4 kW avg cons: 3.93 / 4.56 kW
|
|
Wire Feedstock
|
Diameter: 0.8-1.2 mm / Spool Type: BS300 External wire drum ready
|
|
Product Configurations
|
Single or Dual Wire
|
|
Υλικά
|
Stainless Steels, Carbon Steels, Tool Steels, Nickel Alloys, Titanium, Copper Alloys, Gold alloys and more
|
